Tips On Energy Efficient Windows

Windows bring light, warmth, and beauty into buildings and give a feeling of openness and space to living areas. They can also be major sources of heat loss in the winter and heat gain in the summer. However, when properly selected and installed, windows can help minimize a home's heating, cooling, and lighting costs. This information describes one option-- energy-efficient windows--available for reducing a home's heating and cooling energy requirements.

Controlling Air Leaks

When air leaks around windows, energy is wasted. Energy is also transferred through the centers, edges, and frames of windows.

Eliminating or reducing these paths of heat flow can greatly improve the energy efficiency of windows and, ultimately, of homes. Several options are available to reduce air leaks around windows; the least expensive options are caulking and weather stripping, followed by replacing window frames.

Caulking and Weather Stripping

Caulks are airtight compounds (usually latex or silicone) that fill cracks and holes. Before applying new caulk, old caulk or paint residue remaining around a window should be removed using a putty knife, stiff brush, or special solvent. After old caulk is removed, new caulk can then be applied to all joints in the window frame and the joint between the frame and the wall. The best time to apply caulk is during dry weather when the outdoor temperature is above 45 degrees Fahrenheit (7.2 degrees Celsius). Low humidity is important during application to prevent cracks from swelling with moisture. Warm temperatures are also necessary so the caulk will set properly and adhere to the surface.

Weather stripping is a narrow piece of metal, vinyl, rubber, felt, or foam that seals the contact area between the fixed and movable sections of a window joint. It should be applied between the sash and the frame, but should not interfere with the operation of the window.

Replacing Window Frames

The type and quality of the window frame usually affect a window's air infiltration and heat loss characteristics. Many window frames are available--all with varying degrees of energy efficiency. Some of the more common window frames are fixed-pane, casement, double and single-hung, horizontal sliding, hopper, and awning.

When properly installed, fixed-pane windows are airtight and inexpensive and can be custom designed for a wide variety of applications. However, because they cannot be opened, fixed-pane windows are unsuitable in places where ventilation is required.

Casement, awning, and hopper windows with compression seals are moderately airtight and provide good ventilation when opened. Casement windows open sideways with hand cranks. Awning windows are similar to casement windows except that their hinges are located at the tops of the windows instead of at the sides. Hopper windows are inverted versions of awning windows with their hinges located at the bottom. Windows with compression seals allow about half as much air leakage as double-hung and horizontal sliding windows with sliding seals.

Double-hung windows have top and bottom sashes (the sliding sections of the window) and can be opened by pulling up the lower sashes or pulling down the upper sash. Although they are among the most popular type of window, double-hung windows can be inefficient because they are often leaky. Single-hung windows are somewhat better because only one sash moves. Horizontal sliding windows are like double-hung windows except that the sashes are located on the left and right edges rather than on the tops and bottoms. Horizontal sliding windows open on the side and are especially suitable for spaces that require a long, narrow view. These windows, however, usually provide minimal ventilation and, like double-hung windows, can be quite leaky.

Reducing Heat Loss and Condensation

Manufacturers usually represent the energy efficiency of windows in terms of their u-values (conductance of heat) or their r-values (resistance to heat flow). If a window's r- value is high, it will lose less heat than one with a lower r-value. Conversely, if a window's u-value is low, it will lose less heat than one with a higher u-value. In other words, u-values are the reciprocals of r-values (u-values = 1/r-value). Most window manufacturers use r-values in rating their windows.

The following five factors affect the R-Value of a window:

• The type of glazing material (e.g., glass, plastic, treated glass)
• The number of layers of glass
• The size of the air space between the layers of glass
• The thermal resistance of conductance of the frame and spacer materials
• The "tightness" of the installation (i.e., air leaks-- see previous discussion).

Types of Glazing Materials

Traditionally, clear glass has been the primary material available for window panes in homes. However, in recent years, the market for glazing--or cutting and fitting window panes into frames--has changed significantly. Now several types of special glazing are available that can help control heat loss and condensation.

Low emissivity (low-e) glass has a special surface coating to reduce heat transfer back through the window. These coatings reflect from 40% to 70% of the heat that is normally transmitted through clear glass, while allowing the full amount of light to pass through.

Heat absorbing glass contains special tints that allow it to absorb as much as 45% of the incoming solar energy, reducing heat gain. Some of the absorbed heat, however, passes through the window by conduction and re-radiation.

Reflective glass has been coated with a reflective film and is useful in controlling solar heat gain during the summer. It also reduces the passage of light all year long, and, like heat absorbing glass, it reduces solar transmittance. Plastic glazing materials--acrylic, polycarbonate, polyester, polyvinyl fluoride, and polyethylene--are also widely available. Plastics can be stronger, lighter, cheaper and easier to cut than glass. Some plastics also have higher solar transmittance than glass. However, plastics tend to be less durable and more susceptible to the effects of weather than glass.

Storm windows can increase the efficiency of single-pane windows, the least energy-efficient type of glazing. The simplest type of storm window is a plastic film taped to the inside of the window frame. These films are usually available in prepackaged kits. Although plastic films are easily installed and removed, they are easily damaged and may reduce visibility. Rigid or semi-rigid plastic sheets such as plexiglass, acrylic, polycarbonate, or fiber-reinforced polyester can be fastened directly to the window frame or mounted in channels around the frame--usually on the outside of the building. These more durable materials are also available in kits.

Layers Of Glass and Air Spaces

Standard single-pane glass has very little insulating value (approximately r-1). It provides only a thin barrier to the outside and can account for considerable heat loss and gain. Traditionally, the approach to improve a window's energy efficiency has been to increase the number of glass panes in the unit, because multiple layers of glass increase the window's ability to resist heat flow.

Double-pane windows are usually more efficient than single- pane or storm windows. Double or triple-pane windows have insulating air or gas filled spaces between each pane. Each layer of glass and the air spaces resist heat flow. The width of the air spaces between the panes is important, because air spaces that are too wide (more than 5/8 inch or 1.6 centimeters) have lower r-values (i.e., they allow too much heat transfer). Advanced, multipane windows are now manufactured with inert gases (argon or krypton) in the spaces between the panes because these gases transfer less heat than does air. Multipane windows are considerably more expensive than single-pane windows and limit framing options because of their increased weight.

Frame and Spacer Materials

Window frames are available in a variety of materials including aluminum, wood, vinyl, and fiberglass. Frames may be primarily composed of one material, or they may be a combination of different materials such as wood and vinyl. Each frame material has its advantages and disadvantages. Though ideal for customized window design, aluminum frames cause conductive heat loss (i.e., they have low r-values) and condensation. However, thermal breaks made of insulating plastic strips placed between the inside and outside of the frame and sash greatly improve the thermal resistance of aluminum frames.

Wood frames have higher r-values, are unaffected by temperature extremes, and are less prone to condensation, but they require considerable maintenance in the form of periodic painting. If wood frames are not properly protected from moisture, they can warp, crack, and stick.

Vinyl window frames, which are made primarily from polyvinyl chloride (pvc), offer many advantages. They are available in a wide range of styles and shapes, have moderate to high r-values, are easily customized, are competitively priced, require low maintenance, and mold easily into almost any shape. But vinyl frames are not strong or rigid, which limits the weight of glass that can be used. In addition, vinyl frames can soften, warp, twist, and bow.

Fiberglass frames are relatively new and are not yet widely available. They have the highest r-values of all frames; thus, they are excellent for insulating and will not warp, shrink, swell, rot, or corrode. Fiberglass frames can be made in a variety of colors and can hold large expanses of glass. Some fiberglass frames are hollow; others are filled with fiberglass insulation.

Spacers are used to separate multiple panes of glass within the windows. Although metal (usually aluminum) spacers are commonly installed to separate glass in multipane windows, they conduct heat. During cold weather, the thermal resistance around the edge of a window is lower than that in the center; thus, heat can escape, and condensation can occur along the edges.

Many types of windows and window films are available that serve different purposes. To alleviate these problems, one manufacturer has developed a mulitipane window using a 1/8-inch-wide (0.32 centimeters- wide) PVC foam separator place along the edges of the frame. Like other multipane windows, these use metal spacers for support, but because the foam separator is secured on top of the spacer between the panes, heat loss and condensation are reduced. Several window manufacturers now sandwich foam separators, nylon spacers, and insulation materials such as polystyrene and rock wool between the glass inside their windows.

Additional Options For Reducing Heat Loss

Movable insulation, such as insulating shades, shutters, and drapes, can be applied on the inside of windows to reduce heat loss in the winter and heat gain in the summer. Shading devices, such as awnings, exterior shutters, or screens, can be used to reduce unwanted heat gain in the summer. In most cases, these window treatments are more cost effective than energy efficient window replacements and should be considered first.

Reducing heat loss or gain in homes often includes either improving existing windows or replacing them. Low cost options available for improvement are caulking, weather stripping, retrofit window films, and window treatments. Replacing windows will involve the purchase of new materials, which should adhere to certain energy efficiency standards. Different combinations of frame style, frame material, and glazing can yield very different results when weighing energy efficiency and cost. For example, a fixed-pane window is the most airtight and the least expensive; a window with a wood frame is likely to have less conductive heat loss than one with an aluminum frame; double-pane, low-e window units are just as efficient as triple-pane untreated window's, but cost and weigh less.

No one window is suitable for every application. Many types of windows and window films are available that serve different purposes. Moreover, you may discover that you need two types of windows for your home because of the directions that your windows face and your local climate. To make wise purchases, first examine your heating and cooling needs and prioritize desired features such as day lighting, solar heating, shading, ventilation, and aesthetic value.
